The law of sine “opposite leg / hypotenuse = sine” applies here. Alternatively, you can use the Pythagorean theorem. Rafter = distance between eaves point and ridge beam / roof angleĬonversely, this also results in the roof height. The perpendicular between the peak of the roof and the attic forms the opposite side of the triangle. These forms are simply converted to determine the rafter length and you get: Calculate raftersĪfter all, determining the rafter length is quite simple. The rafter forms the hypotenuse in a right triangle. The roof angle is formed between the rafter and the adjacent side. The length of the rafter can be calculated with the help of the law of cosines “adjacent leg / hypotenuse = cosine” : Roof angle = distance between the eaves point and the ridge beam / rafter This shows how important it is to determine the cover material. The following minimum roof angles apply to common roof coverings: This way, you get a better impression of how pointed or flat the roof will be afterwards. However, this angle is irrelevant for determining the rafter length. The roof angle is the angle between the straight line connecting the ridge beams transverse to their direction and the rafters. It’s not the angle in the rooftop. With a symmetrical roof, however, one can easily deduce the angle at the top of the roof: 180 – 2 x roof angle = angle at the top of the roof.
RAFTER LENGTH TABLE SKIN
The more pointed the roof, the lower the snow load. On the other hand, the rafters are getting longer and the wind pressure is increasing. The flatter the roof, the shorter rafters you can use. On the other hand, the usable space under the roof is reduced until it can practically no longer be used at all. In addition, the desired roof skin sometimes dictates the minimum roof pitch.
RAFTER LENGTH TABLE INSTALL
The rafter length is the diagonal between the ridge and eaves points. Only the distance between these two points is relevant for the calculation of the statics. This means: the rafter can protrude beyond both points. This is largely irrelevant for the statics. The emphasis is on “as far as possible”: it can make sense to extend the rafter well beyond the ridge edge. For example, you can install a vestibule or a carport at the same time. However, the leverage forces that occur must in turn be included in the overall statics. If necessary, the rafter is secured with an additional support. You have to know: Ten centimeters of fresh new snow already produces 100 kg per square meter, which corresponds to one kilonewton (kN). Ten centimeters of compacted old snow can weigh as much as 300 kg. The exact snow load zone can also be obtained from the local town hall. This question is at the very beginning of calculating the rafters. Europe is divided into so-called “snow load zones”. They depend essentially on the height above sea level at which the house is built. In addition, the snow load zones are also assigned to specific regions. There is a map of Europe that shows the snow load zones. In which snow load zone is the house located? Expansion reserves for additional loads (photovoltaic, solar thermal).The following factors are required to calculate the rafter: The type, number and cross-section of the rafters depends on the load they bear under maximum conditions. The load creates bending stress on the rafters. The load acting vertically on the projected area per square meter is always used as the basis. This is important to remember: the more pointed the roof, the longer the rafter placed under the projected square meter will be. However, the compressive stress on the purlins also increases. Overall, calculating a roof truss is a demanding task that should be carried out by a structural engineer.
RAFTER LENGTH TABLE HOW TO
You can always check our website for more content: blog How to calculate rafters? Although architecture is always presenting new concepts for single and multi-family houses, the gable roof house remains the standard in construction to this day. A timbered roof truss is required with a gable roof. The main load of the roof is dissipated by the rafters, the sloping beams. How to calculate the rafters, you will learn in this text.
